Hai hi3518EV300 processor, as a new generation of consumer cameraSOC, integrates a new generation of ISP and the latest H265 video compression encoder in the industry. It leads the industry in low bit rate and high image quality. At the same time, it detects human figures and supports intelligent applications such as face and abnormal sound detection. With advanced low-power technology and low-power architecture design, Hi3518EV300 processor leads the industry in low power consumption. The integration of POR, RTC and audioCodec greatly reduces the eBOM cost for customers.
Processor core
armCortexA7@900MHz，32KBI-Cache，32KBDCache/128KBL2cache
Support Neon acceleration and integrate FPU processing unit.
video coding
H.264BP/MP/HP, supporting I/P frames
H.265Mainprofile, which supports I/P frames
MJPEG/JPEGBaseline coding
Video coding processing performance
H.264/H.265 coding can support a maximum resolution of 2304×1296 and a maximum width of 2304.
H.264/H.265 multi-stream real-time coding capability;
−2048×1536@20fps+720×576@20fps
−2304×1296@20fps+720×576@20fps
−1920×1080@30fps+720×576@30fps
Support JPEG snap 3M(2304×1296)@5fps
CBR/VBR/FIXQP/AVBR/QPMAP/CVBR codes are supported.
Rate control mode
Support intelligent coding mode
Output rate is up to 60Mbps.
Support eight regions of interest (ROI) coding
Intelligent video analysis
Integrated IVE intelligent analysis acceleration engine, humanoid detection, support for intelligent applications such as face and abnormal sound detection.
Support intelligent motion detection, perimeter defense, video diagnosis and other intelligent analysis applications.
